Dispensing Equipment
Dymax manual and automated fluid dispense systems and spray valves are easily integrated into existing manufacturing processes for easy application of coatings, lubricants, or masking resins.
Automotive Parts Assembly
Light-Curable Adhesives and Coatings for Automotive Parts Assembly
Lower your manufacturing costs and manufacture more reliable parts using Dymax LED/UV/Visible light-curing technology. Our automotive adhesives and coatings produce more reliable electronic assemblies, components, headlamps, sound systems, and enable longer-lasting structural assemblies.
Replace time-consuming off-line operations and adhesives with long cure times that are difficult to dispense, control, and maintain. Our curing resins cure in seconds upon exposure to LED or UV/Visible light, activator, or heat, and are designed to be integrated into assembly lines for easier automation. Additionally, many adhesives utilize our unique and patented See-Cure technology, allowing the adhesive to be applied in a colored state to confirm proper application
Features
- Lower product costs
- Reduced life-cycle costs
- Low ecological impact
- Most products are certified as halogen free
- Color change See-Cure technology (some products)
- IPC approved
- Meet or exceed standards set forth in IEC 61249-2-21
- MIL-I-46058C and UL listed self-extinguishing grades available
Product Number
Product Description
Regional Availability
9451
True black thin protective conformal coating for tamper-proofing PCBs. This product is excellent for hiding components, board features, and sensitive information. Optimized for single-pass coating up to 0.004 in. This coating cures upon exposure to UV/Visible light and has a secondary heat-cure capability. UL 94 Flammability V-0 rating.
Product Number
Product Description
Regional Availability
501-E-REV-A
501-E-REV-A Activator, when pre-applied to metallic, plated, ceramic, or glass substrates rapidly cures 600 series and 800 series structural adhesives and thermal interface materials in gaps from less than 1 mil to 20 mils.
9452-FC
Conformal coating with very low viscosity and no added solvents. This product is LED curable at 365/385/405nm and features a secondary heat cure. This film coating provides good electrical insulation and excellent wettability.
3069
Rapidly bond and laminate flexible and rigid substrates including a variety of plastics. The bond strength of this product on PC and PVC usually exceeds the strength of the substrates being assembled.
846-GEL
High-performance structural bonding adhesive ideal for bonding dissimilar substrates where maximum tensile shear strength is required. This product cures using activator.
GA-103
Form-in-place gasket sealant has excellent moisture- and chemical resistance for high-temperature sealing applications and underwater enclosures that require a low compression set. This silicone-free gasket has a self-leveling viscosity and cures with UV/Visible light in seconds.
GA-120
Self-leveling FIP gasket with good deflection is formulated for applications such as speaker assembly and automotive enclosures, which require a soft, tacky, flexible gasket.
9482
Fluorescing conformal coating designed for superior circuit protection with coating thicknesses up to 0.254 mm (0.010 in). This product cures with UV/Visible light first, then over time with a secondary ambient moisture cure. UL 94 Flammability V-0 rating.
9481-E
Formulated to ensure complete cure on high-density PCBs where shadow areas are a concern. This product is optimized for coating thicknesses between 25 mic [0.001 in] and 127 mic [0.005 in] and excels in coating applications where chemical and abrasion resistance is critical. The material cures upon exposure to UV/Visible light and features a secondary moisture cure. UL 94 Flammability V-0 rating.
6-621
Metal bonding adhesive curable with UV/Visible light, heat, or pre-applied activator. Visible light can penetrate through many UV-blocked and colored plastics and glasses. Applications include coil winding, potting, as well as metal-to-glass bonding.
Need help, use the product finder
Use our formulated product finder to help you find the right material. Interested in learning more or have questions? Contact Us, we want to hear from you.
